Description
MASTER XL 9 SR ΘΕΡΜΑΣΤΡΑ ΑΚΤΙΝΟΒΟΛΙΑΣ ΠΕΤΡΕΛΑΙΟΥ
Power:
29 / 43 kW
100.000 / 148.000 Btu/h
25.000 / 37.000 Kcal/h
|
Tank capacity:
60 l |
Fuel consumption:
2,3 / 3,37 kg/h |
Thermostat control:
optional |
Packaging dimension (l x w x h):
1200 x 760 x 1130 mm |
|
Rated current:
0,7 A |
Power supply:
220-240/50 V/Hz |
Net / gross weight:
69 / 85 kg |
Main features
Model descriptionRadiant heating
No air flow
Low noise
Professional oil burner
Electronic flame control with photocell
Possible connection to an optional room thermostat
Post-ventilation
Combustion chamber made of ceramic fibre
Standard oil level indicator
Strong and long lasting construction
Easy maintenance with European standard components
Adjustable direction / Tilting
Two oil filters: oil tank filter and suction filter
|
AccesoriesFuel pre-heater
 Room thermostat TH 5 with cable
range: 0-36°C, accuracy: ± 1,5°C  |
|
How it worksRadiant heating – air flow
 |
RememberVentilation of the room
is neccessary to prevent a deficiency in oxygen supply. Useful links |
|
 |
|
|
Heat distribution
Που μπορείτε να το χρησιμοποιήσετε:
 |
|
 |
|
 |
Θέρμανση χώρων μικρών και μεσαίων διαστάσεων, Ανοιχτούς χώρου και μέρη με πολύ αέρα, Αποθήκες, Ανακαινίσεις και Κατασκευές, Εργοτάξια ανοικτά, Συνεργεία ανοικτά, Τέντες μισάνοιχτες, κλπ
